Fermax Way - Page 14

14
BUS(IM) BUS(DS)
PC6
Exit Button
GNDS1S212V
NCCOMNOGND
AC~
monitor
-
+
L1 L2 PL S+ S-
adaptor for the lock
EM-lock
1# Camera
(Device Address:0)
NO
POWER IN-USE
BUS
GND COM NC
DT-RLC
2-WIRE SYSTEM
12V S2 S1 GND
BUS
RISER
1
2
3
-
+
B.Magnetic lock type:
1
23
ON
DIP
Relay control the second lock of door station 1.
B. Abrepuertas magnético.
Relé para el control del segundo abrepuertas de la puerta 1.
1
2
3
PSU
ref. 1410
B. Gachê électro-magné que.
Relais : commande de la deuxième gâche de la pla ne de rue 1.
B. Elektromagne scher Türöff ner
Relais zur Steuerung des zweiten Türöff ners der Tür 1.
Botón de salida
Exit Button
Bouton-poussoir hall d’entrée
Türöffnungstaste
Botão do hall de entrada.
B. Trinco eletromagnético.
Relé controla o segundo bloqueio da estação de porta 1.
Abrepuertas
Lock
Gachê
Türöffner
Trinco
SIN puente
WITHOUT jumper
SANS jumper
OHNE Steckbrücke
SEM jumper
SIN puente
WITHOUT jumper
SANS jumper
OHNE Steckbrücke
SEM jumper
12V S2 S1 GNDGND NO COM NC
BUS BUS
REF 1418
MODULO RELE WAY
WAY RELAY MODULE
POWER IN-USE
RISER
RoHS
Compliant
