MODEL: №. SBC52 • 02/2020 • 700710

52cc 2 Stroke Brushcutter / Line Trimmer

Connecting the P handle to the Upper shaft

WARNING. The P handle must be tted before use of this product.

This includes both combinations of the Brushcutter or the Line

Trimmer. Ensure the motor is NOT operating when tting or adjusting the

P handle.

NOTE: Always ensure the engine is turned o before undertaking this task.

The P handle assembly consists of an upper and a lower clamp, and 4 x hex

bolts, 4

nuts & 8

washers.

NOTE: The P handle (12) should only be tted on

the upper shaft where the P handle hole (44) on the

underside of the shaft ts with the pin on the internal

side of the P handle lower clamp (12)

1. Lay the unit down so the fuel tank bracket (39) is

resting on a secure / stable surface.

2. Loosen and remove the 4 nuts from the 4 x 5mm

hex bolts for P handle (46), and place the 4 nuts

into the 4 holes on the underside of the P handle

(12) lower clamp. (Fig. D)

3. Locate the P handle middle clamp (45) next to the

P handle hole (44) on the upper shaft, and place

the P handle lower clamp such that the pin aligns

with the P handle hole (44), and the middle clamp

aligns to t inside the P handle lower clamp. (Fig. E)

4. Place the P handle lower clamp over the

underside of the P handle middle clamp (45) so

that the pin engages in the P handle hole (44),

and the lower clamp aligns with the P handle

middle clamp (45). (Fig. E)

5. Place the P handle upper clamp over the lower

P handle clamp, place the 4 x 5mm hex bolts

with washers into the 4 aligned holes of P handle

upper clamp and lower clamp. (Fig. F)
