33
Regular Maintenance
Mowing Height Adjustment
See Figure 35. The mowing height can be adjusted
by turning the cutting height adjustment handle.
To Raise the Mower Deck:
Turn the cutting height adjustment handle (A, Figure
35) CLOCKWISE.
To Lower the Mower Deck:
Turn the cutting height adjustment handle COUNTER-
CLOCKWISE.
Raising the Mower Deck for Transport
To raise the mower deck for transport, pull the deck
transport adjustment handle (A, Figure 35) backwards
and up until it latches into place.
To lower the mower deck to the operating position,
release the deck lift lock lever (B) and slowly lower
the deck transport adjustment handle forward and
down.
Figure 35. Mowing Height Adjustment
A. Cutting Height Adjustment Handle
B. Deck Transport Adjustment Handle
C. Deck Lift Lock Lever
A
B
C
