Ferris IS1500Z Series User Manual

47
THIS IS A 15 DEGREE SLOPE
INSTRUCTIONS 1. Fold this page along the dotted line indicated above. 2. Align the left edge of this guide with a vertical tree, a power line pole, a fence post, or any vertical structure. 3. Compare the angle of the fold with the angle of the hill.
SLOPE INDENTIFICATION GUIDE
ALIGN THIS EDGE WITH A VERTICAL SURFACE
(TREE, POLE, FENCE POST, BUILDING, ETC)
COMPARE THE ANGLE OF THE FOLD TO THE ANGLE OF THE SLOPE
2
3
THIS IS A 10 DEGREE SLOPE
FOLD ALONG APPROPRIATE DOTTED LINE
1
Not for
Reproduction

Ferris IS1500Z Series Specifications

General

Cutting Width	61 in
Cutting Height	1.5-4.5 in
Transmission	Hydro-Gear ZT-3400 Transaxles
Drive System	Hydrostatic
Engine Type	4-Cycle
