10 ferrismowers.com
• seat plate pivots
• deck lift pivot points
• discharge chute hinge
Generally, all moving metal parts should be oiled where
contact is made with other parts. Keep oil and grease off belts
and pulleys. Remember to wipe fittings and surfaces clean
both before and after lubrication.
20
21
22
Lubricate the Front Casters
Interval: Annually
1. Remove the 1/4-28 bolt (A, Figure 23) screwed into the
caster and install a 1/4-28 grease fitting.
23
2. Grease the front caster.
3. Remove the 1/4-28 grease fitting and reinstall the 1/4-28
bolt.
4. Repeat the process for the other side of the machine.
Checking / Adding Fuel
WARNING
Gasoline is highly flammable and must be handled with
care. Allow engine to cool for at least 3 minutes before
refueling. Do not allow open flame, smoking or matches in
the area. Avoid over-filling and wipe up any spills.
To add fuel:
1. Remove the fuel cap (A, Figure24).
To Next Page
