Main Menu – GAINS (Inputs)
The analog inputs of the PULSE16 DX can be set to different
sensitivities in the range from -8dBu up to +20dBu in single steps of
1dB.
The number above the fader shows the maximum level in dBu, which
the input can handle. When the fader is set to “20” like in the picture
above the input can handle an maximum input level of +20dBu. Avoid
exceeding this maximum level to prevent digital clipping.
In addition to the fader you see the input level meters of the analog
inputs of the unit. This makes input setting easier. The dB scale on the
right side shows the resolution of these level meters.
The value of -8dBu is chosen on purpose, because it’s
close to the level of analog consumer gear (-10dBV =
-7.78dBu)
