GENERAL SPECIFICATIONS
WIRING DIAGRAMS
Wiring diagram of basic model ambient thermostat, heat/cool function and speed selector command (on board machi-
ne and wall):
NOTE: Basic thermostat
• Installation on machine and wall
• ON/OFF selector
• Summer mode / winter mode / automatic mode selector
• Three-speed selector
• Set point selector
AMBIENT THERMOSTAT HEAT/COOL FUNCTION - SPEED SELECTOR COMMAND
VERSION ON MACHINE
WALL-MOUNTED VERSION
