5
DESCRIPTION OF THE APPLIANCE
PURPOSE OF THE MACHINE
The convector fan is an appliance that treats the air in the room in both summer (bank supplied with cold water min.
6°C) and winter (bank supplied with hot water max 85°C).
AVAILABLE VERSIONS AND INSTALLATION METHODS
The range of centrifugal convector fans includes three versions. Different power ratings are available for each.
1: VM-B - Convector fan with cabinet and intake from below
Consists of a sheet metal cabinet, a delivery grille with
doors to access the panel (if applicable) made of thermo-
plastic material plus an air filter that can be generated,
installed on a metal frame with covering profile in plastic
material housed on guides formed in the lower part of the
frame.
- Installation mode
VERTICAL WALL-MOUNTED
VERTICAL AND STANDING
HORIZONTAL
