Ferroli 15 - OVERALL DIMENSIONS OF DUCTED MODEL; OVERALL DIMENSIONS OF BRACKETING

GENERAL SPECIFICATIONS
OVERALL DIMENSIONS OF DUCTED MODEL
494
A
216
Ø 16
OVERALL DIMENSIONS OF BRACKETING
278
Ø 16
60494
137.5 137.5
A
Overall dimensions if
applicable
77.5
MODEL 15 20 30 40 50 60 80 100 120
A (mm) 474 474 724 724 974 974 974 1224 1224
Weight (Kg) 11 11 15 15 22 22 22 29 29
MODEL 15 20 30 40 50 60 80 100 120
A (mm) 415 415 665 665 915 915 915 1165 1165
9
