80 EN
cod. 3540000272 - Rev. 01 - 01/2024
b15 Flowmeter type selection
1 = Flow. (450 imp/l)
2 = Flow. (700 imp/l)
3 = Flow. (190 imp/l)
3
b16 Not implemented -- --
b17 Not implemented -- --
b18
DHW mode activation flow
rate
0-100 l/min/10 25
b19
DHW mode deactivation
flow rate
0-100 l/min/10 20
b20 Flue material selection
0 = Standard
1 = PVC
2 = CPVC
0
b21 Not implemented -- --
b22 Not implemented -- --
b23
Standard flue shutdown
maximum temperature
60-110°C 105
b24
PVC flue shutdown maxi-
mum temperature
60-110°C 93
b25
CPVC flue shutdown maxi-
mum temperature
60-110°C 98
b26 Not implemented -- --
b27 Calibration type
0 = Manual
5 = Complete manual
0
b28 Not implemented -- --
b29 Restore Factory Values
Change the value from 0 to 10 by pressing the "DHW +"
button. Confirm by pressing the "heating +" button. (By res-
toring Factory Values, parameter b27 is automatically set
to 5 and parameter b02 to 2.) Therefore parameter b02
must be set to the correct value according to the boiler
model.
0
P30 Heating ramp
10÷80
(ex. 10=20°C/min, 20=12°C/min, 40=6°C/min, 80=3°C/min)
40
P31 Heating standby time 0-10 minutes 4
P32 Heating Post-Circulation 0-255 minutes 15
P33 Pump operation
0 = Continuous pump (active only in winter mode)
1 = Modulating pump
1
P34 Pump modulation DeltaT 0 ÷ 40°C 20
P35
Modulating pump min.
speed
30 ÷ 100% 40
P36
Modulating pump start
speed
90 ÷ 100% 90
P37
Modulating pump max.
speed
90 ÷ 100% 100
P38
Pump deactivation tempera-
ture during Post-Circulation
0 ÷ 100°C 55
P39
Pump activation hysteresis
temperature during Post-
Circulation
0 ÷ 100°C 25
P40 Heating user max. setpoint 20 ÷ 90°C 80
P41 Max. output in heating 0 ÷ 100%
24 kW = 80
28 kW = 85
34 kw = 90
P42 Burner shutdown in DHW
0 = Fixed
1 = Linked to setpoint
2 = Solar
0
P43
Comfort mode activation
temperature
0 ÷ 80°C 40
Index Description Range Default
