Ferroli F24
23
Fig. 27h Fig. 27i
8. Install the inner metal flue into the outlet, up to
the wallplate flange mark.
9. Lift boiler with flue in place, engage inner and
outer flue, slide into position
9. Make sure the inner flue is fully engaged in
the flue terminal, secure boiler with two nuts
and washers, sevure bottom of boiler using two
screws and washers.
80 mm
36 mm
