Festo KBS-FEC FC30- 0206NH English34
General information
Degree of protection IP 20
Protection class Protection class III. Power packs
conforming to IEC 742/EN
60742/VDE 0551/PELV and with
at least 4 kV insulation resis-
tance, or power packs that guar-
antee reliable isolation as defined
in E N 60950/VDE 0805
1)
.
I/O connections Screw-type terminal
Nominal cross-section 2 x 0.75 mm
2
Tightening torque for screws
(screw-type terminals)
max. 0.5 Nm
EMC E N 61000-6-2, EN 50081-2
1)
The entire device should be assigned to class II if non- P ELV electrical circuits are
switched via the relay o utputs.
