Festo KBS-FEC FC30- 0206NH English 35
Digital inputs
Number 12 / 2 groups; 1 x 4 inputs, 1 x 8
inputs; both groups electrically
isolated from one another. The in-
puts in a group should be either
current-sinking or current-sourc-
ing.
Number of inputs that can be
used as high-speed counters
(max. 2 kHz)
2
Input voltage / current 24 V DC, input current 7 mA
1)
Value for TRUE 15 V DC min.
Value for FALSE 5VDCmax.
Input signal delay typically 5 ms
Electrical isolation yes, optocoupler
Permitted length of connecting
cable
max. 30 m
Status display with LED yes
Insulation resistance against in-
ternal system voltage
Rated voltage of insulation: 50 V
AC
1)
The input voltages should be generated from electrical circuits from protection class
II I. This requirement is fulfilled if the sensor supply v oltage is used.
