Menu Level 2 "Output"
The menu option "Output" only appears if "Input type" = "Analog" has been selected.
Menu option Contents Description
"Output type" "Analog"/"Digital" Appears only for voltage variants. For current vari-
ants, "Output type" = "Analog".
– "Analog": The current actual pressure is output
as an analogue voltage / current value via the
actual value output.
– "Digital": A digital 24 V signal is output via the
actual value output, which switches as soon as
the actual value is within the parameterised lim-
its.
"Output max" E.g.5V Appears only if "Output type" = "Analog".
Upper limit of the electrical actual value output in
analogue mode
"Output min" E.g.0V Appears only if "Output type" = "Analog".
Lower limit of the electrical actual value output in
analogue mode
"Digital out" "High OK"/"Low OK" Appears only if "Input type" = "Digital".
Switchover of the meaning of high or low signal at
the digital output:
– "High OK":High is output if the actual value lies
within the parameterised limits.
– "Low OK":Low is output if the actual value lies
within the parameterised limits.
"Hysteresis +/-" E.g.0.200bar Appears only if "Input type" ="Digital"
Setting of the limits for the digital output. The set
value corresponds to the maximum deviation from
the setpoint value, which is evaluated as OK for the
digital output.
"Output delay" E.g.100ms Appears only if "Input type" ="Digital"
Delayed output of edge changes at the actual value
output in order to filter short status changes
(forexample with setpoint value jumps). Shorter
pulses than defined in "Output delay" are not out-
put.
Commissioning
15Festo — VPPI-...-D — 2019-12
