Functional description
The pictures for the functional description are on a
fold-out page at the beginning of the instruction
manual. When reading of the manual you can fold
out this page for having always an overview of the
machine.
Accessories shown or described are sometimes not
included in the scope of delivery.
Charger TCL 3
Mains voltage (input) 230 - 240 V ~
Mains frequency 60 Hz
Charging voltage (output) 10,8 - 18 V=
Rapid charging max. 3 A
Conservation charging, intermittent (NiCd, NiMH) approx. 0,06 A
Charging times for BP, BPS and BPC battery packs
Li-ion 1,5 Ah, 80 %/100 % approx. 25/35 min.
Li-ion 3,0 Ah, 80 %/100 % approx. 55/70 min.
Li-ion 4,2 Ah, 80 %/100 % approx. 70/90 min.
Permitted operating temperature range -5 °C to +45°C
Temperature monitoring via NTC resistor
Safety class /II
Battery pack BPC 18 4,2 Ah LiIon
Voltage 18 V
Capacity 4,2 Ah
Weight 0,68 kg (1.5 lbs)
[1-1]
Tool adapter
[1-2]
Release sleeve
[1-3]
Right/left switch
[1-4]
On/Off switch
[1-5]
Drilling/hammer drilling selector switch
[1-6]
Belt clip
[1-7]
Battery pack
[1-8]
Button for releasing the battery pack
[1-9]
Capacity display
[1-10]
LED lamp
[1-11]
Auxiliary handle
[1-12]
Depth stop
