17
Fault Cause Adjustment
B5 dowel hole not parallel
to workpiece edge
workpiece has shifted during
processing
secure workpiece properly
B6 dowel hole not at right
angles (90°) to work-
piece surface
a) deposits (e.g. chips) below the
base plate
b) angle guide not set exactly to 90°
c) worked on without angle bracket
a) remove deposits
b) set angle guide to 90° exactly
c) use angle bracket
9a,
9b
The position of the
dowel holes, which
were created with the
left and right stop latch,
does not exactly match
(different distance to
workpiece edge).
The midpoint between the two
stop latch is not exactly in the
midpoint of the swivel range of
the jointer bit.
Remove one of the stop latches
(9.1) (Fig. 9a). Attach one of
the accompanying stop latches
(9.2) to the dowel jointer (Fig.
9b).These stop latches are nar-
rower and allow you to make
more accurate adjustments.
