5 Technical data
Cordless percussion drill PDC 18/4
Motor voltage 18 V
No-load speed* 1st gear
0 - 400 min
-1
2nd gear
0 - 850 min
-1
3rd gear
0 - 1850 min
-1
4th gear
0 - 3800 min
-1
Max. torque Soft material (wood) 40 Nm
Hard material (metal) 60 Nm
Adjustable torque** 1st gear 1.2 - 11.5 Nm
2nd gear 0.8 - 7.2 Nm
3rd gear 0.6 - 4.7 Nm
4th gear 0.6 - 2.6 Nm
Chuck clamping range 1/16" - 1/2" (1.5 - 13 mm)
Drill diameter max. Wood 1 31/32 (50 mm)
Metal 1/2" (13 mm)
Fastening in pine max. ∅ 3/8" (10 mm)
Tool holder in drill spindle 1/4"
Weight (incl. additional handle, battery pack BP 18 Li 6,2 AS and chuck) as per
EPTA procedure 01:2014
5.2 lbs (2.4 kg)
Weight with Centrotec, without additional handle, without battery pack. 2.9 lbs (1.3 kg)
* Speed specifications with fully charged bat
tery pack.
** The maximum speed is reduced in the lower
torque stages (values in clockwise rotation).
6 Functional description
[1-1]
LED light switch
[1-2]
LED lamp
[1-3]
Bit store
[1-4]
On/Off switch
[1-5]
Clamping sleeve
[1-6]
Drilling/impact drilling selector
switch
[1-7]
Gear switch
[1-8]
Torque thumbwheel
[1-9]
Right/left switch
[1-10]
Belt clip
[1-11]
Button for releasing the battery pack
[1-12]
Insulated gripping surfaces (grey
shaded area)
[1-13]
Capacity display button on battery
pack
[1-14]
Capacity indicator
Accessories shown or described are not always
included in the scope of delivery.
The pictures for the functional description are
on a fold-out page at the beginning of the in
struction manual. While reading the manual
you can fold out the page for comparison and
quick reference.
7 Commissioning
7.1 Changing the battery pack
Inserting the battery pack [2A]
