14
1 Symbols
Warning of general danger
Risk of electric shock
Wear ear protection.
Wear a dust mask!
PRECISIO CS 70 E, CS 70 EB
Table of contents
1 Symbols 14
2 Technical data 14
3 Machine features 14
4 Intended use 14
5 Safety instructions 15
5.1 Machine-related safety
instructions 15
5.2 Emission levels 15
5.3 Other risks 16
6 Commissioning 16
6.1 Assembling the machine 16
6.2 On/Off switch 16
7 Machine settings 16
7.1 Electronics 16
7.2 Set-up position 17
7.3 Adjusting the cutting depth 17
7.4 Adjusting the mitre angle 17
7.5 Changing tools 17
7.6 Setting the spacer wedge 18
7.8 Fitting the splinterguard 19
7.9 Dust extraction 19
8 Working with the machine 19
8.1 Using the machine as a bench-
mounted circular saw 19
8.2 Using the machine as a trimming
saw 19
9 Service and maintenance 20
10 Accessories 20
11 Disposal 20
12 Warranty 21
13 EU Declaration of Conformity 21
2 Technical data
Cutting depth at 90°/45° 0 - 70 mm/
0 - 48 mm
Inclination -2° - 47°
Max. cutting length 330 mm
Saw blade 225 x 30 x 2.5 mm
Idling speed
CS 70 EB, adjustable 2000 - 4200 rpm
CS 70 E 4200 rpm
Power consumption 2,200 W
Table dimensions (L x W) 690 x 500 mm
Bench height with foldaway legs 900 mm
Bench height without
foldaway legs 375 mm
Weight with foldaway legs 34 kg
Protection category of motor (CS 70 EB
only) and IP5X switch according to EN 60529.
The specifi ed illustrations are at the begin-
ning of this operating manual.
3 Machine features
[1-1] Foldaway legs
[1-2] On/off switch
[1-3] Cable holder
[1-4] Table insert
[1-5] Rotary knob for adjusting the fence
[1-6] Spacer wedge
[1-7] Stop lever
[1-8] Cutting depth adjuster
[1-9] End cap
[1-10] Groove
[1-11] Rotary knob for adjusting the pro-
tective cover
[1-12] Knobs for adjusting the foldaway
legs
4 Intended use
The PRECISIO is a portable electric power
tool designed for sawing wood, plastics,
wooden panel material and material with
similar properties to wood.
Special aluminium cutting blades supplied
by Festool allow you to use these machines
to saw aluminium. Materials containing as-
bestos must not be processed.
The user bears the responsibility for damage
