Festool RTS 400 REQ User Manual

10
Intended use
The sanders are designed for sanding wood, plas-
tic, stone, composites, paint/varnish, filler and sim-
ilar materials as directed. Metals and materials
that contain asbestos must not be processed.
To guarantee electrical safety, the machine must
not be damp or operated in a damp environment.
The machine must only be used for dry sanding.
The user is liable for improper or non-in-
tended use.
Technical data
Functional description
The pictures for the functional description are on a
fold-out page at the beginning of the instruction
manual. While reading the manual you can fold out
the page for comparison and quick reference.
Accessories shown or described are sometimes not
included in the scope of delivery.
Orbital sander DTS 400 REQ RTS 400 REQ
Power 250 W 250 W
No-load speed 6000 - 12000 min
-1
6000 - 12000 min
-1
Max. speed
1
16000 min
-1
16000 min
-1
Sanding stroke 5/64" (2.0 mm) 5/64" (2.0 mm)
Sanding pad 4"x 6"
(100 x 150 mm)
3-5/32" x 5-1/4"
(80 x 130 mm)
Weight (without mains cable, with sanding pad) 2.6 lbs (1.2 kg) 2.6 lbs (1.2 kg)
Safety class /II /II
1.
Max. speed in the event of faulty electronics.
[1-1] On/Off switch
[1-2] Plug it-connection
[1-3] Speed control
[1-4] Extractor connector
[1-5] Sanding pad
[1-6] Protector
[1-7] Long-life dust bag
[1-8] Dust bag adapter
[1-9] Handle (insulated gripping surface)

Festool RTS 400 REQ Specifications

General

Type of sander	Orbital sander
Dust extraction port	Yes
Power	250 W
Dust container type	Dust bag
Idle speed (max)	12000 RPM
Idle speed (min)	6000 RPM
Idle oscillation rate (max)	24000 OPM
Idle oscillation rate (min)	12000 OPM
Power source	AC

Weight and Dimensions

Weight	1200 g
Sanding plate size (WxD)	80 x 130 mm
