[1-1] Buttons for releasing the battery pack
[1-2]
Capacity display button on battery pack
[1-3] Capacity display
[1-4] LED lamp
[1-5] Electronic speed selection
[1-6] On/off switch
[1-7] Locking sleeve
[1-8] Rotational direction switch and safety lock/transport lock
[1-9] Bit store
[1-10] Belt clip
[1-11] Insulated gripping surfaces (grey shaded area)
Accessories shown or described are not always included in the scope of delivery. The specified illustrations appear at
the beginning of the operating manual.
Commissioning
Belt clip [1-10]
The belt clip allows the power tool to be attached to work attire for brief periods. It can be attached to the right or left of
the power tool using a screw [1a].
Switching on/off [1-6]
Press = ON, release = OFF
CAUTION
Risk of injury
Do not look directly into the LED light. [4]
The LED light [1-4] lights up when the on/off switch [1-6] is pressed.
Set the rotational direction switch/safety lock [1-8] to the centre position to lock the on/off switch.
