Contact Information
FETCO
Food Equipment Technologies Company
600 Rose Road
Lake Zurich • IL • 60047-0429 • USA
Internet: www.fetco.com
Phone: (800) 338-2699 (US & Canada)
(847) 719-3000
Fax: (847) 719-3001
Email: sales@fetco.com
techsupport@fetco.com
Product Description/Features
CBS-61H - Single Coffee Brewing System
CBS-62H - Twin Coffee Brewing System
• 3 gallon, thermal, portable, all stainless steel dispensers
Optional Features:
• Stainless steel, gourmet size brew baskets • Half batch brewing capability
• Brew basket double safety locks
(Can be added at any time)
• Open type, leak free dispense system • Color stainless steel finish
• Fully automatic, with electronic temperature control • Custom and export voltage
• Mercury type power contactor
• Two level tank drain system
• Total serviceability from the front
Technical Data
Brewing Specification
Brew Volume: Temperature:
Full Batch 3 gal. (11.4 lit.)
205°F inside water tank (at sea level)
Half Batch 1.5 gal. (5.7 lit.)
195°F ± 5° at sprayhead
Brew Time: Bypass Range: 0 to 33%
Full Batch 5 - 5.5 min.
(Factory set at 0% unless specified)
Half Batch 2.5 – 2.75 min.
(Allow an extra 2-4 minutes for coffee to finish dripping)
Water Requirements:
CBS-61H: 20-75 psig, 1 gpm
Coffee Filter Size: 20” X 8” – standard FETCO # F004
CBS-62H: 20-75 psig, 2 gpm
18” X 7½” - optional half batch FETCO # F005
Weights and Capacities
Brewer
Model
Weight
(empty)r
Water tank
Capacity & Weight
Weight
(filled)
Dispenser
Weight, ea.
Dispenser
Filled, ea.
Total Weight Brewer
& Dispensers, Filled
CBS-61H 111 lbs. 8 gal. 66.4 lbs. 177 lbs. 18 lbs. 42.5 lbs. 220 lbs.
CBS-62H 195 lbs. 14 gal. 116.2 lbs. 311.2 lbs. 18 lbs. 42.5 lbs. 397 lbs.
