PRIME MOVER SPECIFICATIONS
IMPORTANT Exceeding any of the maximum recommended prime mover specifications
CAN result in damage to this product and
WILL void all FFC warranties.
DESCRIPTION SPECIFICATIONS
Weight of Prime Mover without Cold Planer 11,000 lbs. maximum
Operating Capacity of Prime Mover's Loader 4,500 lbs. maximum
Lift Capacity of Prime Mover's Loader 9,000 lbs. maximum
Hydraulic Pressure Output 5,000 psi maximum
Rear Ballast As required to maintain full prime mover stability.
(Note the Shipping Weight on the specifications page,
then see the operator’s manual(s) for your prime mover,
loader, and quick-attach for ballasting needs.)
COLD PLANER SPECIFICATIONS
Model
Number
Cutting
Width
Cutting
Depth
Tilt Sideshift
Overall
Width
Overall
Height
Overall
Depth
Shipping
Weight
LAF5416
SSP16HF
16" 0 - 6" ± 15° 24" 66" 33" 60" 1572 lbs.
LAF5418
SSP18HF
18" 0 - 6" ± 15° 24" 66" 33" 60" 1646 lbs.
LAF5420
SSP20HF
20" 0 - 6" ± 15° 24" 66" 33" 60" 1721 lbs.
LAF5424
SSP24HF
24" 0 - 6" ± 15° 24" 66" 33" 60" 1797 lbs.
LAF5430
SSP30HF
30" 0 - 6" ± 12.5° 24" 66" 33" 60" 1940 lbs.
LAF5436
SSP36HF
36" 0 - 6" ± 10° 24" 66" 33" 60" 2135 lbs.
COLD PLANER REQUIREMENTS
Model Number Required Pressure Required Flow
LAF5416 SSP16HF 2200 psi 24 gpm
LAF5418 SSP18HF 2200 psi 26 gpm
LAF5420 SSP20HF 2200 psi 26 gpm
LAF5424 SSP24HF 2200 psi 28 gpm
LAF5430 SSP30HF 2200 psi 28 gpm
LAF5436 SSP36HF 2200 psi 31 gpm
