DCP-10
Page 19/27
8.5 Calibration Menu:
NO. Items Preset Value Range
5.1 GEN. V1 offset
±10.0%
5.2 GEN. V2 offset
±10.0%
5.3 GEN. V3 offset
±10.0%
5.4 Current I1 offset
±10.0%
5.5 Current I2 offset
±10.0%
5.6 Current I3 offset
±10.0%
5.7 Pressure offset
±10.0%
5.8 Temperature offset
±10.0%
5.9 Batt. V offset
±10.0%
8.6 The optional items for P/T-sensor:
Code The brand model of LOP sensor The brand model of HET sensor
0 not used not used
1 close for low oil pressure close for high temperature
2 open for low oil pressure open for high temperature
3 VDO 5 bar
VDO 120 ℃
4 VDO 10 bar
VDO 150 ℃
5 Datcon 7 bar Datcon
6 Murphy 7 bar Murphy
7 Pre-set 1 PT100
8 Pre-set 2 Pre-set 1
9 Pre-set 3 Pre-set 2
10 Pre-set 4 Pre-set 3
11 configured by user Pre-set 4
12 configured by user
NOTE:
 When the controller leaves factory, the optional types and functions of
LOP sensor and HET sensor have been preset as the above table. If the
using sensor is not listed in this table, the user can select “configurable”,
and write sensor parameters to controller via software.
 LOP sensor parameter addendum：
VDO 5 bar:
VDO 10 bar:
P(Bar)
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5
P(PSI)
0 7.3
14.5
21.8
29.0
36.3
43.5
50.8
58.0
65.3
72.5
R(Ω)
11 29 47 65 82 100 117 134 151 167 184
P(Bar)
0.0 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 10.0
P(PSI)
0 14.5
29.0
43.5
58.0
72.5
87.0
101.5
116.0
130.5
145.0
R(Ω)
10 31 52 71 90 106 124 140 155 170 184
