Fiammastore
39
EN
Troubleshooting
FR
Que faire en cas de problème
ES
Intervencion en caso de problemas
EN
1 - Completely open the awning.
2 - Lightly loosen the screw A.
3 - Unscrew, till nearly take it out, the dowel for regulation (it is a stop screw).
4 - Then operate on screw B, gradually, rotating clockwise to rise the arm and
rotating anti clockwise to lower it always checking that the lead bar moves in a
horizontal position.
5 - Once found the right adjust, screw in the screw C till the stop and then lock the
screw A.
These operations can inhibit the regulation of the inclination of the lead bar (p. 28),
you must proceed very gradually.
