NOTE: The system uses R-1234yf (refrigerant) which
does not pollute the environment in the event of acciden-
tal leakage. Under no circumstances is the use of R-134a
(refrigerant) allowed.
Automatic Climate Controls — If Equipped
1. Driver Temperature Control
Provides the driver with independent temperature con-
trol. Rotate the adjustment knob to set desired tempera-
ture shown in the Temperature Display. Rotate fully
counter-clockwise for maximum A/C (LO).
2. A/C Button
Push the A/C Control Button to change the current
setting. The indicator illuminates when the A/C is ON.
Pushing the AUTO control button will cause the A/C
operation to change to AUTO mode and the A/C indi-
cator will turn OFF.
3. MAX Defrost Button
Push the MAX Defrost button to change the current
airflow setting to Defrost mode. The indicator illuminates
when this feature is ON. Performing this function will
cause the automatic climate controls to change to manual
mode. The blower speed increases to full (all LEDs ON)
Automatic Climate Controls
4
GETTING TO KNOW YOUR VEHICLE 113
