The LaneSense button is located on the end of the turn
signal stalk located on the steering column.
To turn the LaneSense system ON, push the Lane
Assist button (LED turns OFF). A “Lane Sense
On” message is shown in the EVIC.
To turn the LaneSense system OFF, push the Lane Assist
button once (LED turns ON).
NOTE: The LaneSense system will retain the last system
state ON or OFF from the last ignition cycle when the
ignition is changed to the ON/RUN position.
LaneSense Warning Message
The LaneSense system will indicate the current lane drift
condition through the Electronic Vehicle Information
Center (EVIC).
3.5 EVIC Screen
When the LaneSense system is ON, the lane lines are gray
when both of the lane boundaries have not been detected
and the LaneSense indicator is solid white.
System ON (Gray Lines/White Indicator)
7
STARTING AND OPERATING 327
