145
TOWING THE CAR
37)
Version with Dualogic gearbox
Make sure that the gearbox is in neutral
(N) (checking that the vehicle moves
when pushed) and proceed in the
same way as for towing a normal
vehicle with a manual gearbox.
If the gearbox cannot be put in neutral,
do not tow the vehicle and contact a
Fiat Dealership.
ATTACHING THE
TOW RING
The tow ring provided with the car is
housed in the tool box under the boot
mat.
Proceed as follows:
❒ release the front cap
A-fig. 134 or the rear cap fig. 135;
❒ take the tow hook B from its
housing in the tool support;
❒ fully tighten it on the threaded pin.
134 - front
DVDF0S0203c
135 - rear
DVDF0S0204c
