29
STEERING WHEEL LOCK
2)
Engagement: when the key is in
position STOP, remove the key and
turn the steering wheel until it is locked.
Disengagement: move the steering
wheel slightly as you turn the ignition
key to MAR.
Height adjustment: operate lever
B-fig. 13 to lift or lower the rear part of
the cushion to achieve the most
comfortable driving position.
Backrest folding: To fold the
backrest over, adjust lever D-fig. 14
(movement 1) and push the backrest
forwards until it locks (movement 2);
release lever D and, pushing the
backrest, slide the seat forwards
(movement 3).
13
DVDF0S013c
SEATS
3) 4) 2)
FRONT SEATS
Longitudinal adjustment: lift lever
A-fig. 11 and push the seat forwards
and backwards to reach the required
position.
Backrest angle adjustment: rotate
the knob C-fig. 12.
11
DVDF0S012c
12
DVDF0S014c
