KNOWING YOUR CAR
30
Driver and passenger sides
with position memory:
to restore the seat to its original
position, slide the seat backwards
pushing the backrest until the seat
locks (movement 4), adjust lever D-fig.
14 (movement 5) and raise the
backrest (movement 6) until the locking
movement can be heard.
Passenger side with no position
memory: to restore the seat to its
original position, slide the seat
backwards pushing the backrest until
the desired position is reached
(movement 4), adjust lever D-fig.14
(movement 5) and raise the backrest
(movement 6) until the locking
movement can be heard.
14
DVDF0S015c
HEAD RESTRAINTS
3) 5)
ADJUSTMENTS
Upward adjustment: raise the head
restraint until it clicks into place.
Downwards adjustment: press
button A fig.15 and A fig.16 and lower
the head restraint.
IMPORTANT When the rear seats are
in use, the head restraints must always
be in the position of use.
15
DVDF0S015c
16
DVDF0S015c
