KNOWING YOUR CAR
52
Versions with colour display
When the sensors are activated, the
screen in fig. 52 appears on the
display.
Obstacle presence and distance
information is therefore provided both
by the acoustic signal and the
instrument panel display.
51
DVDF0S0182c
52
DVDF0S0459c
The system indicates a detected
obstacle by displaying an arc
according to the distance of the
obstacle and its position in relation to
the car.
If an object is detected in the rear left,
central or right zone, the display shows
a flashing arc in the corresponding
zone and a sound is emitted.
As the car approaches the object, the
display shows one or more flashing
arcs that approach the car, and the
sound becomes more frequent until it
becomes continuous.
The colour on the display depends on
the distance from and position of the
obstacle.
The car is close to the obstacle when a
blinking red arch appears on the
display (to the right, in the centre or to
the left) and a continuous sound is
emitted. If there are several obstacles,
the closest one is indicated.
Fault indications
Any parking sensor faults will be
indicated when reverse is engaged by
the warning light
è
(or the icon t on
the colour display) in the instrument
panel and by the relevant message in
the display (for versions/markets,
where provided).
Operation with a trailer
Sensor operation is automatically
deactivated when the trailer’s electrical
cable plug is inserted.
