Charge Times
Type Of Charge Approximate Time
Level 1 (120V/15A)
Approximately 23 hours to fully recharge
* 3 hours will restore 10 miles of range *
Level 2 (240V/30A)
Approximately 4 hours to fully recharge
* 30 minutes will restore 10 miles of range *
The following factors determine how long a battery recharge will take:
• The battery’s current state of charge (percent depleted)
• What recharging device is being used (Level 1 or Level 2)
• Ambient temperatures
NOTE:
• Charging times are estimates based on a completely discharged high voltage battery
pack.
• Charging times will vary based on the age, condition state of charge and temperature
of the high voltage battery pack.
EVSE Operation And Status Information
Indicator Description
1 — AC Indicator LED
Green indicates READY
RED Indicates a fault
2 — Fault Indicator LED
Green indicates READY
RED indicates a fault
3 — Charge Level Indicator LED's
All ON indicates system ready and not
charging
LED's turning on and off in sequence
indicates vehicle charging
• When the EVSE is first plugged in it will go through an initialization and self test. For
the first three seconds after plugging in your EVSE all the LED's will remain off.
• After approximately three seconds the EVSE performs an internal self test and
Ground Continuity Test . This process takes approximately six seconds.
• During the internal self test the unit turns on one Charge Level Indicator LED every
1.5 seconds until all the Charge Level Indicator LED's are illuminated.
AC LED
Fault Indicator
LED
Charge Level Indicator LED's Time
• • •ooo
1.5 sec
• • ••oo 3.0 sec
• • •••o 4.5 sec
• • •••• 6.0 sec
GETTING STARTED
14
