• If the self test is successful the AC LED, the Fault Indicator LED and the four Charge
Level LED's will turn solid green.
• The EVSE LED's will be used to indicate the vehicle's connection status if no faults are
found during the self test.
AC LED
Fault Indicator
LED
Charge Level Indicator LED's
••••••
• After the EVSE is connected to the vehicle's charge inlet the EVSE will continue to
illuminate all LED's green.
• Once the vehicle begins charging t he EVSE Charge level LED's will illuminate in order
from left to right, then shut off. This pattern will repeat as long as the EVSE remains
connected to AC power and the battery is charging.
• The LED's are illuminated and turn off at the rate of one change per second.
AC LED
Fault Indicator
LED
Charge Level Indicator LED's Time
• • •ooo
1.0 sec
• • ••oo 2.0 sec
• • •••o 3.0 sec
• • •••• 4.0 sec
NOTE:
Refer to the Level 1 User Manual for any additional information on its use or operation.
CAUTION!
Do not bend or damage the Level 1 EVSE terminals as this could cause the EVSE to
become inoperative and/or illuminate the fault LED.
GETTING STARTED
15
