SERVICING AND MAINTENANCE 285
3. Disconnect the connector, then undo the
two screws to access the bulbs.
Tail Light Access
4. Locate faulty bulb and press slightly and
turn at the same time: counterclockwise to
extract; clockwise to install.
5. Reposition the bulb holder assembly in the
headlight body, proceed until you hear the
tabs click.
6. Reinstall tail lamp assembly and close
liftgate.
License Plate Lights
See below steps for bulb replacement:
To replace the bulbs proceed as follows:
1. Using a suitable tool remove the license
plate lens.
License Plate Light Location
License Plate Light
2. Remove the bulbs from the individual side
contacts.
Lamp Assembly
1 — Bulb Holder
2 — Bulb
8
