286 SERVICING AND MAINTENANCE
3. Insert the new bulbs, and ensure that they
are properly locked between the contacts.
4. Reinstall the license plate lens.
NOTE:
If removal the license plate lens using a suitable
tool, be sure to cover the tip of the suitable with
a cloth so no damage is done to the lenses or
the vehicle paint.
Replacing Interior Bulbs
Front Courtesy Light
See below steps for bulb replacement:
1. Using a suitable tool remove the front
courtesy light as shown.
Front Courtesy Light Housing
2. Release the retainer clips and bulb housing
as shown.
Front Courtesy Bulb Housing
3. Replace the bulbs by pulling straight out of
bulb housing.
Front Courtesy Bulb Housing
4. Insert the new bulbs, making sure that they
are properly locked.
5. Reassemble the bulb housing and courtesy
light housing making sure that they are
properly locked.
6. Install the front courtesy light making sure
that it is properly locked.
1 — Retaining Clips
2 — Bulb Housing
