IN AN EMERGENCY
148
REPLACING AN
EXTERNAL BULB
Main beam/dipped beam
headlights (halogen)
To replace the bulb, proceed as
follows:
working from inside the engine
compartment, remove rubber cap (A)
fig. 121, using the dedicated tab;
121 F1B0146C
press the electric connector (B)
fig. 122 downwards to release the bulb
and bulb holder assembly from the
housing;
122 F1B0710
pull out the bulb holder outwards;
disconnect the electrical connector
(B) and replace the bulb (C).
then insert the bulb and bulb holder
assembly in its housing and press it
until you hear it lock. Make sure it is
locked correctly;
refit the rubber cap (A).
IMPORTANT Only replace the bulb
when the engine is off. Also ensure that
the engine is cold, to prevent the risk of
burns.
LED main beam / dipped beam
headlights / fog lights
For replacing these bulbs, contact a
Fiat Dealership.
Side lights/daytime running lights
(DRL) (LED)
(where provided)
To replace them, contact a Fiat
Dealership.
Side lights/daytime running lights
(DRL) (halogen)
To replace the bulbs, proceed as
follows:
steer the vehicle wheels completely
inwards;
123 F1B0147C
124 F1B0253C
using the screwdriver provided, undo
the screws (A) fig. 123 and remove the
inspection flap (B);
identify the side light/daytime running
light bulb;
