203
WHEELS
RIMS AND TYRES PROVIDED
195) 196)
Alloy or pressed steel rims. Tubeless radial carcass tyres. All approved tyres are listed in the Registration Document.
IMPORTANT If there are any discrepancies between the Owner Handbook and the Registration Document, take the information
from the latter. For safe driving, the car must be fitted with tyres of the same make and type on all wheels.
IMPORTANT Do not use inner tubes with tubeless tyres.
Wheels Tyres provided Aftermarket winter tyres
6.5J x 16 H2 ET40 215 / 60 R16 95H 215 / 60 R16 95Q (M+S)
6.5J X 19” ET35 5x110 (°) 205 / 50 R19 94H (**) 205 / 50 R19 94Q (M+S)
7J x 17 H2 ET40 215 / 55 R17 94V (*) 215 / 55 R17 94Q (M+S)
7J x 18 H2 ET40
225 / 45 R18 91V (**)
225 / 45 R18 91Q (M+S)
225 / 45 R18 91Y (**)
7.5J X 19” ET40 (°°) 225 / 40 R19 93Y XL Runflat (**) 225 / 40 R19 93Q (M+S)
(*) Mandatory tyre for some specific versions/markets.
(**) Tyres not suitable for fitting snow chains
(°) For 1.0 / 1.3 / 1.3 Multijet / 1.6 Multijet versions
(°°) 1.0 / 1.3 / 1.4 Turbo Multi Air / 1.3 Multijet / 1.6 Multijet
On versions with 215/60 R16 and 215/55 R17 tyres, use smaller snow chains with a maximum projection of 7 mm beyond the
tyre profile.
Space-saver spare wheel (where provided)
Rim: 4.0 x 16 / Tyre: T145/90 R16 106M
COLD TYRE INFLATION PRESSURE
When the tires are warm, the inflation pressure should be + 0.3 bar in relation to the recommended figure. However, recheck
that the value is correct with the tyre cold.
With snow tyres, add +0.2 bar to the pressure value prescribed for standard tyres.
If it is necessary to raise the vehicle, refer to the "Raising the vehicle" paragraph in the "In an emergency" chapter.
