TECHNICAL SPECIFICATIONS
202
Versions 1.3 95 HP E6DFinal 1.6 16V Multijet 130HP
Engine code 46345266 46346020
Cycle Diesel Diesel
Number and position of cylinders 4 in line 4 in line
Piston bore and stroke (mm) 69.6 x 82 79.5 x 80.5
Total displacement (cm³) 1248 1598
Compression ratio 16.2 15.7
Maximum power (CEE) (kW) 70 96
Maximum power (CEE) (HP) 95 130
Corresponding engine speed (rpm) 3750 3750
Maximum torque (CEE) (Nm) 200 320
Corresponding engine speed (rpm) 1500 1500
Fuel
Automotive Diesel
(EN590 specifications)
Automotive Diesel
(EN590 specifications)
WARNING
194)
Modifications or repairs to the fuel supply system that are not carried out properly or do not take the system’s technical specifications
into account can cause malfunctions leading to the risk of fire.
