157
emergency sunroof operation (where
provided);
138 F1B0218C
raise the mat (A) fig. 139 and take the
space-saver wheel (B);
position the spare wheel and tool
bag next to the wheel for changing;
139 F1B0219C
take the chock (A) (where provided)
fig. 140and fold it out as shown in the
diagram;
place the chock (A) on the wheel
diagonally opposite the one to be
replaced (see fig. 141) to prevent the
vehicle from moving irregularly when it
is lifted from the ground;
140 F1B0220C
141 F1B0221C
use wrench (A) fig. 142 to loosen
the fixing stud bolts by about one turn.
For versions with alloy rims it is a good
idea to "shake" the car to facilitate
detachment of the rim from the wheel
hub;
position the jack under the vehicle,
near the wheel to be changed;
142 F1B0223C
insert the wrench (A) fig. 143 on
the hexagonal part of the jack (B) to
extend it until the top splined area fits
correctly into the side member (C) of
wheel chock (F) (where provided); tow
ring (G); wrench (H) wheel stud bolt
and jack wrench; hex wrench (I) for
