Fiat Capron A68 - Toilet Cassette Emptying; Sewage Tank Emptying

117Capron - 04-17 - CAP-0017-01EN
Sanitary fittings
11
Emptying:  Turn the slide lever (Fig. 112,1) in a clockwise direction. The sliding trap is
closed. To empty, the sliding trap in the Thetford toilet must be closed.
 Remove and empty the Thetford cassette.
11.6.2 Emptying the sewage tank
 Slide the slide lever on the toilet bowl in a clockwise direction. The sliding
trap is closed.
 Open the flap for the sewage tank on the outside of the vehicle. Insert the
key into the locking cylinder (Fig. 113,1) of the push-button lock and turn a
quarter turn in a clockwise direction.
 Remove the key.
 Press both push-button locks (Fig. 113,2) simultaneously with your thumb
and open the flap for the sewage tank.
 Swivel flap fully upwards and carefully set on the exterior wall. The flap is
kept open magnetically.
 Pull the retaining clip (Fig. 114,2) upwards and pull out the sewage tank
(Fig. 114,1).
 Completely empty the sewage tank at disposal stations that are especially
provided for this purpose.
Z The sewage tank can only be taken out if the sliding trap is closed.
Fig. 113 Flap for the sewage tank Fig. 114 Sewage tank
Z Actuate the aeration knob on the sewage tank with your thumb to empty it
completely.
