To lower the seat: whilst sitting, move
the lever B (front part of the seat) or
the lever C (rear part of the seat)
upwards and position your body weight
on the part of the seat to be lowered.
Backrest angle adjustment
Turn the knob D fig. 15.
18)
Lumbar adjustment
Operate the knob E fig. 16 to adjust.
SPRUNG SEAT
The seat is equipped with a mechanical
spring system and hydraulic shock
absorber to ensure maximum comfort
and safety. The system of springs
also effectively absorbs impact from
uneven road surfaces.
See the description in the "Seats"
section for the lengthwise adjustments,
height adjustments, backrest
adjustment, lumbar adjustment and
armrest adjustment.
Ballast weight adjustment
Use the knob A fig. 17 to set the
desired adjustment according to your
body weight, in the range 40 kg to 130
kg.
19) 20) 21) 22) 23)
SEAT WITH REVOLVING
BASE
(for versions/markets, where provided)
It may be turned through 180° toward
the seat on the opposite side. Operate
the control A fig. 18 to turn the seat.
Before turning the seat, it must be
moved forward and only then adjusted
longitudinally fig. 19.
CARGO SPACE
(For versions/markets, where provided)
Depending on the version, you can
request an additional load compartment
fig. 20 located behind the cab.
16
F1A0022
17
F1A0023
18
F1A0025
12
19
F1A0026
17
