REPLACING
INTERIOR BULBS
For the type of bulb and relevant power
rating, see “Changing a bulb”.
FRONT CEILING LIGHT
To replace the bulbs, proceed as
follows:
operate in the point shown by the
arrow and remove the roof light A
fig. 145;
open protective flap B fig. 146;
replace the bulbs C fig. 146
by releasing them from the side
contacts and making sure that the new
bulbs are correctly secured between
the contacts;
re-close the flap B fig. 146 and
fasten the roof light A fig. 145 in its
housing, making sure that it locks into
place.
REPLACING FUSES
GENERAL INFORMATION
141) 142) 143) 144)
47)
Fuses protect the electrical system:
they intervene (blow) in the event of a
failure or improper action on the
system. When a device does not work,
check the condition of its protection
fuse: the filament A fig. 147 must be
intact. If it is not, replace the blown fuse
with another with the same amperage
(same colour).
B intact fuse.
C fuse with damaged filament.
145
F1A0208
146
F1A0209
147
F1A0212
151
