25
END OF CHARGING
PROCEDURE
The charging procedure ends when
all the LEDs (A)fig.30, located next to
the charging port, will light up steady
green (during the charging phase, on
the other hand, the LEDs will light up
flashing/fixed green according to the
state of charge of the battery portion
indicated by the LED. The fixed green
light indicates that the battery portion
is fully charged).
DISCONNECTING THE
"MODE2" CHARGING
CABLE
During the charging procedure the
cable is automatically locked on the
charging port in the vehicle.
To complete the charging, proceed as
follows:
 unlock the doors of the vehicle
allowing the charging cable to
unlock;
 if charging is in progress, press
button on the charging port;
 disconnect the cable from the
vehicle charging port by grasping
the grip of the charging connector
and avoiding to pull the cable
directly;
 disconnect the cable from the
charging port fig.33;
33 F1A1067
 replace the protective cover of the
charging port;
 close the charging flap, making
sure it locks properly;
 roll up the charging cable correctly,
repositioning the protective
cover correctly on the charging
connector (where provided). When
rolling up, take care not to damage
the cable. Then store the cable
together with the charging kit.
WARNING Before disconnecting the
charging connector, make sure that
the doors are unlocked. If the door
is locked, the charging connector
locking system does not allow
disconnection.
REFUELLING THE
VEHICLE
(hydrogen versions)
Only use hydrogen that complies with
European standards DIN EN 17124 or
ISO 14687 or equivalent.
A label on the fuel filler flap indicates
the type of hydrogen fuel allowed, as
well as the maximum filling pressure
(MFP) and nominal operating pressure
(NWP).
In Europe, filling nozzles at petrol
stations are marked with the same
symbols. Always refuel with the
permitted type of fuel.
