❒ remove the bulb D, E, F pushing it
gently and turning it anticlockwise
(“bayonet” locking), then replace
it; remove the bulb G, H pulling
outwards;
❒ refit the bulb holder and tighten the
screws C;
❒ reconnect the electrical connector,
correctly reposition the unit on the
body of the vehicle and then tighten
the fixing screws B;
❒ refit the plastic cover fastening it with
the 7 fixing screws A.
For truck and chassis
cab versions:
Undo the four screws H fig. 217 and
replace the bulbs:
I bulb for rear fog light
L bulb for reversing light
M bulb for side light
N bulb for brake light
O bulb for side light.
.
THIRD BRAKE LIGHTS
T
o replace the bulb proceed as follows:
❒ undo the two fixing screws fig. 218;
❒ extract the lens unit;
❒ press in the tabs B fig. 219 and
remove the bulb holder;
❒ remove the snap-fitted bulb and
replace.
217
F1A0200
218
F1A0204
219
F1A0205
220
