❒ raise the lever A (movement 3), until it
is above the retaining cursor C fig. 31
(located at the side) which
guarantees that the system is raised
firmly during the operations.
Once the base is released, it will be
possible to work on the seat using both
hands to move it forwards or
backwards fig. 32.
It will also be possible to remove it,
working on the seat where the clips are
free in relation to the openings in the
rails; in this position (which can easily
be achieved by sliding the base a
little and simultaneously extracting it)
the seat can easily be removed fig. 33.
After the sliding and removal
operations, the seat should be refitted
and secured to the rails on the floor
before driving, as follows:
❒ fit the base on the rails;
❒ push the retaining lever downwards
fig. 34, applying suitable force, until
the system is locked.
IMPORTANT The locking system is only
secured when the safety clip under
the lever locks it horizontally. If this does
not happen, check that the seat is in
the exact locking position in relation to
the rail (moving the seat backwards
or forwards a few millimetres until it is
properly attached). Once the
quick-release base is locked in position,
it will be as in the first stage, in other
words with the retaining lever perfectly
parallel to the floor guaranteeing that
the seat is securely fastened in the
selected position.
30
F1A0388
31
F1A0389
32
F1A0390
33
F1A0391
34
F1A0392
22
KNOW YOUR VEHICLE
