The following table has the same information as the previous diagram to show how to respect current laws.
5-seater combi versions
Child restraint
systems
The child's weight
ISOFIX child seat
dimensions
Passenger front
seat
Rear side seat Rear central seat
Transverse cot
Group 0
<to10kg
F
X IL (1) X
G
Child restraint seat
facing backwards
Groups 0 and 0+
<to13kg E X IL(2) X
Child restraint seat
facing backwards
Groups 0 and 1+
<to13kgandfrom
9to18kg
C, D X IL (2) X
Child seat facing
forward Group 1
from 9 to 18 kg A, B, B1 X IUF/IL (3) X
Booster seat
Groups 2 and 3
from 15 to 25 kg and
from 22 to 36 kg
X IUF/IL (3) X
X = Seat not authorised to install an ISOFIX child restraint.
IUF/IL = For vehicles that allows it, it allows attaching thanks to the ISOFIX fasteners for a "Universal/semi-universal or
vehicle-specific" approved child car seat; check possible installation.
(1) The cot is installed crosswise with respect to the vehicle and takes up at least two seats. The child's head must be opposite
the vehicle's door.
(2) Move the front seat as far forward as possible to install the child seat backwards from driving direction, then move it back to
maximum so it does not come into contact with the child seat.
(3) Child seat facing forward: position the child seat backrest in contact with the seat backrest. In any case, remove the rear
seat headrest that the child seat is positioned against. This should be done before positioning the child restraint system (refer to
the "Rear headrest" paragraph in the "Knowing your vehicle” chapter). Do not move the seat in front of the child back more
than half the distance and do not incline it more than 25°.
120
SAFETY
