Fiat TALENTO - Halogen Daytime Running Lights; LED Daytime Running Lights; Main and Low Beam Headlights; Replacing an External Bulb

160) Halogen bulbs contain pressurised
gas, in the case of breakage they may
burst causing glass fragments to be
projected outwards.
161) Only replace bulbs when the engine is
off. Also ensure that the engine is cold, to
prevent the risk of burns.
162) The bulbs are under pressure and
could explode when being replaced. Risk
of injury.
REPLACING AN
EXTERNAL BULB
163) 164) 165) 166) 167)
28)
LED daytime running lights (1
fig. 236 )
Contact a Fiat Dealership.
Halogen daytime running lights
Turn the bulb holder A fig. 237 a quarter
turn anticlockwise and pull it out.
Types of bulbs: W21W/5W.
Replace the bulb and reposition the
holder.
Main and low beam headlights
Turn the guard B fig. 237 a quarter turn
anticlockwise.
Disconnect the connector 3 fig. 238.
Unhook the spring 2 fig. 238 and
remove the bulb.
Type of bulb: H4.
1
236
T40633
237
T36663
2
3
238
T36664
147
