Vehicles complete and with no further changes. Measurements i millimetres

VAN

Short wheelbase (L1) Long wheelbase (L2)

Low roof (H1) High roof (H2) Low roof (H1) High roof (H2)

A 3098 3098 3498 3498

B 4999 4999 5399 5399

C 933 933 933 933

D 968 968 968 968

E 1615 1615 1615 1615

F 1628 1628 1628 1628

G 2283 2283 2283 2283

H 1971 2493 1971 2490

J 552 552 552 552

Q 1387 1898 1387 1898

Y 1391 1391 1391 1391

Z 1320 1820 1320 1820

Z1 2537 2537 2937 2937
