Fiat TALENTO - Page 198

To Next Page

To Previous Page

Vehicles complete and with no further changes. Measurements i millimetres

COMBI M1

Short wheelbase (L1) Long wheelbase (L2)

Low roof (H1) Low roof (H1)

5/6 passengers 8/9 passengers 5/6 passengers 8/9 passengers

A 3098 3098 3498 3498

B 4999 4999 5399 5399

C 933 933 933 933

D 968 968 968 968

E 1615 1615 1615 1615

F 1628 1628 1628 1628

G 2283 2283 2283 2283

H 1971 1971 1971 1971

J 552 552 552 552

Q 1369 1369 1369 1369

Y 1391 1391 1391 1391

Z 1320 1320 1320 1320

Z1 1650 736 2050 1136
