Vehicles complete and with no further changes. Measurements i millimetres

CREW CAB

Short wheelbase (L1) Long wheelbase (L2)

Low roof (H1)

A 3098 3498

B 4999 5399

C 933 933

D 968 968

E 1615 1615

F 1628 1628

G 2283 2283

H 1971 1971

J 552 552

Q 1387 1387

Y 1391 1391

Z 1320 1320

Z1 (min/max) 1914 / 2023 2314 / 2423
