Version Combi M1

Long wheelbase (L2) – Low roof (H1)

Engine type Ecojet 95 Ecojet 125 - Ecojet 145 Ecojet 95 Ecojet 125 - Ecojet 145

5/6 passengers 8/9 passengers

Capacity 1200 kg

Gear order weight 1914 1924 1977 1987

Maximum carrying

capacity (including the

driver)

1096 1096 1033 1033

Total weight on the

ground

3010 3020 3010 3020
